+1 646 481 7757Bi-ocular Thermal Imager with Daylight Camera and Laser Range Finder (LRF) for Day or Night Use
Bi-ocular multi-function thermal imager with daylight camera and Laser Range Finder (LRF). TiCAM 1200 is a versatile security, surveillance and observation sensor for day and night use. The device is based on a Thermoteknix high resolution uncooled thermal imaging core along with a visible daylight CCD channel. It features a Laser Range Finder (LRF), Digital Magnetic Compass (DMC) and real-time in-camera digital recording, providing accurate location and co-ordinates.
Lightweight and compact, TiCAM 1200 is suitable for forward observation units, infantry, border security, police, special units and search and rescue. Dual OLED displays ensure maximum comfort for long-term surveillance.
TiCAM 1200 operates from internal AA batteries or external power. It can be connected to various information/command systems for real-time data exchange.
TiCAM 1200 is available in two models; TiCAM 1200 with LRF range up to 5,000m and TiCAM 1200+ with LRF range up to 10,000m.
TiCAM 1200 is compatible with Thermoteknix ConnectIR Android application or Thermoteknix ConnectIR-TAK plugin for use with ATAK-MIL or ATAK-CIV
INTUITIVE USER INTERFACE
The TiCAM 1200 has a novel and unique interface that is intuitive, and is easy to learn and operate its full functionality in the field.
POWERFUL MULTI-SENSOR CAPABILITY
TiCAM 1200 is based on a Thermoteknix 640 x 480 12μm uncooled microbolometer uncooled thermal imager and daylight CCD electo-optical bore sighted channel for true 24-hour operation.
ATAK-MIL AND/OR ATAK-CIV COMPATIBLE
Compatible with Thermoteknix ConnectIR Android application or Thermoteknix ConnectIR-TAK plugin for use with ATAK-MIL or ATAK-CIV for real-time data exchange.
640 x 480 resolution
AA Battery Powered
Digital Magnetic Compass
Laser Range Finder
Non-ITAR
| Specification | ||
|---|---|---|
| Technical Data | TiCAM 1200 | TiCAM 1200+ |
| LRF Range | 5,000m | 10,000m |
| LRF Wavelength | Eye Safe 1,550nm | Eye Safe 1,550nm |
| Weight | <1,670g (excluding batteries) | <1,700g (excluding batteries) |
| Infrared Detector | 640 x 480 12µm | 640 x 480 12µm |
| Daylight CCD Channel | Digital Visual Colour Camera | Digital Visual Colour Camera |
| Display | Dual OLED | Dual OLED |
| In Camera Recording | Real time digital still/video | Real time digital still/video |
| Digital Magnetic Compass | Yes | Yes |
| GPS | Yes | Yes |
| Laser Pointer | Yes | Yes |
| Power | AA batteries | AA batteries |
